emec LASP4 EPDM suction lance with 40cm immersion length (LASP4) - M12 plug for connection to Prisma pump

Product number: 896305

Product information "emec LASP4 EPDM suction lance with 40cm immersion length (LASP4) - M12 plug for connection to Prisma pump"

Suction lance for extracting a medium directly from a supply container (canister/IBC/CNT tank/barrel)

Foot valve with pre-filter and non-return valve. The level switch generates a digital empty signal. Venting nipple 4mm for return of venting hose from dosing pump or overpressure/multifunction valve.

Our suction lances can be adjusted in height, this means that, for example, instead of pumping from a 50 litre container, you can also pump from a 10, 20 or 30 litre container with the 40cm suction lance.

Series: LASP4
  • Material O-ring: EPDM (neutral) or FP (Viton)
  • Immersion length: 40cm, 75cm or 122cm
  • Connection on the unit side: M12 or BNC
  • Thread/hose connection (mm): 1/2 4x6 (suction capacity max 10l/h)
  • Number of suction connections: 1-suction connection
  • Mounting connection: C61 canister connection (for 40cm suction lance) or mounting connection 1 1/2" CNT/IBC (for 122cm suction lance)
  • Number of floats/switching direction/electrical connection: 1st level/N.O/M12(PRIUS/PRISMA)
  • Length of connection cable: 3.5m
  • Intake filter: LASP4
  • Special feature: Valve ball ceramic

Dimensions

Height 10,5 cm
Length 74 cm
Width 11,5 cm

Weight

Weight 710 g

Other attributes

Country of origin IT
Customs tariff number 84139100
