UVprofessional Pool medium pressure unit 42 m³/h

Product number: 891167

Product information "UVprofessional Pool medium pressure unit 42 m³/h"

UV medium-pressure systems for water disinfection and the decomposition of organically bound chlorine (chloramines) in swimming pool water.

The cost-effective UV-C disinfection is excellently suited for swimming pool water, swimming pool attractions, fountains and pond systems. UV treatment does not introduce any unwanted by-products into the water that could lead to possible side effects such as skin or eye irritation. UV treatment provides supplementary protection against chlorine-resistant organisms and reduction of algae formation in swimming and garden ponds without endangering the animal and plant population of the pond facilities. UV disinfection in swimming pool attractions and fountains prevents bacteria from aerosols from being inhaled.

Stainless steel reactor (1.4571 DIN EN 10217-7, external electropolished) with flange connections according to DIN 2642, quartz immersion tube and UV medium pressure lamp, electronic ballast in sheet steel housing with multifunctional UV monitor with coloured background lighting, operating hours counter, manual/auto switch, power supply (3L, N, PE, 380/400V ±10%, 50/60 Hz) incl. UV monitoring system (ÖVGW / DVGW sensor), remote control input, temperature monitoring and signal outputs.


Pool MS 14:
Flow rate: 14 m³/h at 600 J/m²
UV lamp: 1x 650 Watt
Connection: DN 65, PN10
Pool MS 24:
Flow rate: 24 m³/h at 600 J/m²
UV lamp: 1x 1000 Watt
Connection: DN 65, PN10
Pool MS 42:
Flow rate: 42 m³/h at 600 J/m²
UV lamp: 1x 2000 Watt
Connection: DN 65, PN10
Pool MS 131:
Flow rate: 131 m³/h at 600 J/m²
UV lamp: 1x 3000 Watt
Connection: DN 150, PN10
Pool MS 247:
Flow rate: 247 m³/h at 600 J/m²
UV lamp: 1x 5000 Watt
Connection: DN 200, PN10

Other attributes

Anwendungen Swimming pool
Brand Neomeris
Country of origin EU
Customs tariff number 84212100
Technical specifications



  Pool MS 14 Pool MS 24 Pool MS 42 Pool MS 131 Pool MS 247
Flow rate m³/h at 600 J/m²:
(Qmax at T1cm 98%)
14 24 42 131 247
Connection: DN 65, PN10 DN 65, PN10 DN 65, PN10 DN 150, PN10 DN 200, PN10
Reactor dimensions in mm LxW  560 x 245 600 x 300 600 x 300 750 x 380 850 x 400
UV lamp: 1x 650 Watt 1x 1000 Watt 1x 2000 Watt 1x 3000 Watt 1x 5000 Watt
Power rating: 650 Watt 1100 Watt 2000 Watt 3000 Watt 5000 Watt
Control cabinet material: Steel sheet
Dimensions in mm: 500 x 500 x 300 600 x 380 x 350 600 x 380 x 350 600 x 380 x 350 600 x 380 x 350
