Cooler consists of Titanium steel 1.4571 for automatic sampling to 120°C hot water.
Max.water pressure/hot water: 16 bar
Max.water pressure/cold water: 8 bar
Connections:
Cold water inlet: ½
Cold water outlet (canal): ½
Hot water (in- and outlet): 8 mm
Dimensions: 546 x 128 mm
You can find a detailed description of the cooler in the technical data sheet for download on this page.
Cooler consists of Titanium steel 1.4571 for automatic sampling to 200°C hot water.
Max.water pressure/hot water: 16 bar
Max.water pressure/cold water: 8 bar
Connections:
Cold water inlet: ½
Cold water outlet (canal): ½
Hot water (in- and outlet): 8 mm
Dimensions: 546 x 128 mm
You can find a detailed description of the cooler in the technical data sheet for download on this page.
Cooler consists of Titanium steel 1.4571 for automatic sampling to 80°C hot water.
Max.water pressure/hot water: 16 bar
Max.water pressure/cold water: 8 bar
Connections:
Cold water inlet: ½
Cold water outlet (canal): ½
Hot water (in- and outlet): 8 mm
Dimensions: 598 x 335 mm
You can find a detailed description of the cooler in the technical data sheet for download on this page.
Cooler consists of Titanium steel 1.4571 for manual sampling to 120°C hot water.
Max.water pressure/hot water: 16 bar
Max.water pressure/cold water: 8 bar
Connections:
Cold water inlet: ½
Cold water outlet (canal): ½
Hot water (in- and outlet): 8 mm
Dimensions: 598 x 335 mm
You can find a detailed description of the cooler in the technical data sheet for download on this page.
Cooler consists of Titanium steel 1.4571 for for manual sampling to 80°C hot water.
Max.water pressure/hot water: 16 bar
Max.water pressure/cold water: 8 bar
Connections:
Cold water inlet: 8 mm
Cold water outlet: ½
Hot water (in- and outlet): 8 mm
Dimensions: 413 x 335 mm
You can find a detailed description of the cooler in the technical data sheet for download on this page.
Maintenance kit for Neomeris Select chlorine dioxide sensorEnsure proper operation and high measurement accuracy with our chlorine dioxide sensor service kit and also extend the life of the sensor.Content:1x Replacement membrane cap1x Replacement pressure relief strap2x 30-mL bottles of electrolyte refill solution2x 10-mL syringes3x Polishing squares
Maintenance kit for Neomeris Select free chlorine sensorEnsure proper operation and high measurement accuracy with our free chlorine sensor service kit and also extend the life of the sensor.Content:1x Replacement membrane cap1x Replacement pressure relief strap2x 30-mL bottles of electrolyte refill solution2x 10-mL syringes3x Polishing squares
The calibration box is used for the calibration of Modbus sensors. The wires from the sensors are connected to the terminal block on the front of the box and the Box is connected to a computer via a USB interface.Advantages:Simple and safe calibration of the Modbus sensors
Our Neomeris Select flow cell for free chlorine and chlorine dioxide enables highly accurate measurements by preventing the formation of air bubbles at the sensor membrane while maintaining laminar flow across the membrane.Our flow cell is fully compatible with free chlorine and chlorine dioxide sensors.
Allows for highly accurate measurements: Maintains laminar flow through the system and prevents air bubbles from forming, increasing measurement accuracy.Easy sensor installation: Mount your free chlorine or chlorine dioxide sensor in the flow cell in less than 5 minutes.
